Fiting metric 24/24
Niplu dublu metric cu etanșare pe con de 24 de grade la ambele capete, în optsprezece combinații de mărimi. Niplul de serviciu al instalațiilor metrice. Fiecare capăt primește olandeza liniei lui pe conul de 24 de grade, iar combinațiile inegale fac trecerea între mărimi.
Două furtunuri sau două linii metrice se leagă astfel cap la cap. Optsprezece combinații, de la 10 x 1 în sus.
Variante disponibile
| Cod produs | T (filet exterior) | T1 (filet exterior) | hex E | U.M. | Preț | Cant. | |
|---|---|---|---|---|---|---|---|
| FMD 10 | 10 x 1 | 10 x 1 | 14 | buc | 11.28 RON | ||
| FMD 10/12 | 10 x 1 | 12 x 1.5 | 17 | buc | 10.47 RON | ||
| FMD 10/14 | 10 x 1 | 14 x 1.5 | 19 | buc. | 9.40 RON | ||
| FMD 12 | 12 x 1.5 | 12 x 1.5 | 17 | buc. | 10.86 RON | ||
| FMD 12/14 | 12 x 1.5 | 14 x 1.5 | 19 | buc. | 9.25 RON | ||
| FMD 12/16 | 12 x 1.5 | 16 x 1.5 | 22 | buc. | 13.28 RON | ||
| FMD 12/18 | 12 x 1.5 | 18 x 1.5 | 24 | buc. | 13.92 RON | ||
| FMD 12/20 | 12 x 1.5 | 20 x 1.5 | 24 | buc. | 13.39 RON | ||
| FMD 14 | 14 x 1.5 | 14 x 1.5 | 19 | buc. | 10.72 RON | ||
| FMD 14/16 | 14 x 1.5 | 16 x 1.5 | 22 | buc. | 13.28 RON | ||
| FMD 14/18 | 14 x 1.5 | 18 x 1.5 | 24 | buc. | 11.38 RON | ||
| FMD 14/20 | 14 x 1.5 | 20 x 1.5 | 27 | buc. | 13.11 RON | ||
| FMD 14/22 | 14 x 1.5 | 22 x 1.5 | 27 | buc. | 12.49 RON | ||
| FMD 14/26 | 14 x 1.5 | 26 x 1.5 | 30 | buc | 16.18 RON | ||
| FMD 16 | 16 x 1.5 | 16 x 1.5 | 24 | buc. | 10.34 RON | ||
| FMD 16/18 | 16 x 1.5 | 18 x 1.5 | 24 | buc | 12.44 RON | ||
| FMD 16/20 | 16 x 1.5 | 20 x 1.5 | 27 | buc. | 11.40 RON | ||
| FMD 16/22 | 16 x 1.5 | 22 x 1.5 | 27 | buc. | 13.07 RON | ||
| FMD 16/24 | 16 x 1.5 | 24 x 1.5 | 32 | buc. | 15.34 RON | ||
| FMD 16/26 | 16 x 1.5 | 26 x 1.5 | - | buc. | 15.11 RON | ||
| FMD 18 | 18 x 1.5 | 18 x 1.5 | 24 | buc | 12.93 RON | ||
| FMD 18/20 | 18 x 1.5 | 20 x 1.5 | 27 | buc. | 14.30 RON | ||
| FMD 18/22 | 18 x 1.5 | 22 x 1.5 | 27 | buc. | 13.92 RON | ||
| FMD 18/24 | 18 x 1.5 | 24 x 1.5 | 32 | buc. | 13.92 RON | ||
| FMD 18/26 | 18 x 1.5 | 26 x 1.5 | 32 | buc. | 16.25 RON | ||
| FMD 20 | 20 x 1.5 | 20 x 1.5 | 27 | buc. | 11.45 RON | ||
| FMD 20/22 | 20 x 1.5 | 22 x 1.5 | 27 | buc. | 14.30 RON | ||
| FMD 20/24 | 20 x 1.5 | 24 x 1.5 | 32 | buc. | 15.99 RON | ||
| FMD 20/26 | 20 x 1.5 | 26 x 1.5 | 32 | buc. | 21.06 RON | ||
| FMD 20/27x1.5 | 20 x 1.5 | 27 x 1.5 | - | buc | 12.88 RON | ||
| FMD 20/27x2 | 20 x 1.5 | 27 x 2 | - | buc | 16.25 RON | ||
| FMD 22 | 22 x 1.5 | 22 x 1.5 | 27 | buc. | 14.04 RON | ||
| FMD 22/24 | 22 x 1.5 | 24 x 1.5 | 32 | buc. | 17.17 RON | ||
| FMD 22/26 | 22 x 1.5 | 26 x 1.5 | 32 | buc | 17.17 RON | ||
| FMD 22/27x1.5 | 22 x 1.5 | 27 x 1.5 | - | buc | 16.25 RON | ||
| FMD 22/27x2 | 22 x 1.5 | 27 x 2 | 32 | buc | 16.25 RON | ||
| FMD 24 | 24 x 1.5 | 24 x 1.5 | 32 | buc. | 16.38 RON | ||
| FMD 24/26 | 24 x 1.5 | 26 x 1.5 | 32 | buc. | 19.84 RON | ||
| FMD 24/30 | 24 x 1.5 | 30 x 2 | 41 | buc | 22.88 RON | ||
| FMD 24/30x1.5 | 24 x 1.5 | 30 x 1.5 | 41 | buc | 15.11 RON | ||
| FMD 26 | 26 x 1.5 | 26 x 1.5 | 32 | buc | 17.66 RON | ||
| FMD 26/30 | 26 x 1.5 | 30 x 2 | 41 | buc. | 22.88 RON | ||
| FMD 27x1.5 | 27 x 1.5 | 27 x 1.5 | 32 | buc | 16.25 RON | ||
| FMD 27x2 | 27 x 2 | 27 x 2 | 32 | buc | 17.18 RON | ||
| FMD 30 | 30 x 2 | 30 x 2 | 41 | buc. | 24.06 RON | ||
| FMD 30S | 30 x 2 | 30 x 2 | 41 | buc. | 22.99 RON | ||
| FMD 30/36 | 30 x 2 | 36 x 2 | 41 | buc. | 28.69 RON | ||
| FMD 30S/36S | 30 x 2 | 36 x 2 | - | buc. | 21.68 RON | ||
| FMD 32/36 | 32 x 2 | 36 x 2 | 41 | buc. | 23.74 RON | ||
| FMD 36 | 36 x 2 | 36 x 2 | 41 | buc. | 43.18 RON | ||
| FMD 36S | 36 x 2 | 36 x 2 | 41 | buc | 47.86 RON | ||
| FMD 36/42 | 36 x 2 | 42 x 2 | 46 | buc. | 49.20 RON | ||
| FMD 36S/42 | 36 x 2 | 42 x 2 | 46 | buc. | 48.96 RON | ||
| FMD 42 | 42 x 2 | 42 x 2 | 46 | buc. | 63.72 RON | ||
| FMD 42/45 | 42 x 2 | 45 x 2 | 55 | buc. | 74.38 RON | ||
| FMD 45 | 45 x 2 | 45 x 2 | 55 | buc. | 74.38 RON | ||
| FMD 52 | 52 x 2 | 52 x 2 | 60 | buc. | 148.75 RON | ||
| FMD 52S | 52 x 2 | 52 x 2 | - | buc. | 148.75 RON | ||
| FMD 30x1.5 | 30 x 1.5 | 30 x 1.5 | 41 | buc | 22.88 RON |
